Shihlin electric SS2 Series User Manual

Parameter Description
Parameter Description
103
Para-
meter
Terminal
Factory
Setting
Setting
Range
Value Function Name Function Description Remarks
82 M2 4
0~41
,
43~45
8 RT
When RT is on, the
characteristics are the same
as the second function.
Please refer to
P.44
9
EXJ
(External JOG)
At the external mode, the
target frequency is set by
P.15 and the acceleration/
deceleration time is set by
P.16 when EXJ is on (Note
4).
83 STF 0
0~40
,
43~45
10 STF+EXJ
Multiplexed function
The
multiplexed
function is the
complex of
several basic
functions. It
means that one
multiplexed
terminal can
be used to
realize several
basic
functions.
11 STR+EXJ
12 STF+RT
13 STR+RT
14 STF+RL
15 STR+RL
16 STF+RM
17 STR+RM
18 STF+RH
19 STR+RH
20 STF+RL+RM
21 STR+RL+RM
22 STF+RT+RL
23 STR+RT+RL
24 STF+RT+RM
25 STR+RT+RM
26 STF+RT+RL+RM
27 STR+RT+RL+RM
84 STR 1
0~40
,
43~45
28 RUN
At the external mode, the
inverter runs when RUN is
on.
29 STF/STR
At the external mode, it is
used with RUN. The
inverter runs forwards when
STF/STR is on, and runs
reversely when STF/STR is
off.
Run forward
/reverse
control signal
30 RES External Reset
31 STOP
At the external mode, it can
be used as a three-wire
mode with the RUN signal
or the STF/STR terminal
(note 4).
32 REX Multi-speed
