Shihlin electric SS2 Series User Manual

Parameter Description
Parameter Description
104
Para-
meter
Termi
nal
Factory
Setting
Setting
Range
Value Function Name Function Description Remarks
84 STR 1
0~40
, 43~45
33 PO
At the external mode,
programmed operation
mode is chosen when
PO is on.
34 RES_E
When the alarms
occur, external Reset
became effective
86 RES 30
0~40
, 43~45
35 MPO
At the external mode,
manually operation
circle mode is chosen
when MPO is on.
36 TRI
Triangle wave
function is chosen
when TRI is on.
37 GP_BP
Automatic switchover
frequency between
inverter and
commercial
power-supply
operation
38 CS
Manual switch for
commercial
power-supply.
39
STF/STR
+STOP
At the external mode,
it is used with RUN.
The inverter runs
reverse when
STF/STR is on and
stops when STF/STR
is off. If you need runs
forwards, you should
RUN again.
40 P_MRS
When P_MRS is
turned on, the output
stop immediately
.
P_MRS is a
pulse signal
41 P_FRE Frequency set by pulse
Only for
terminal M2
43 RUN_EN
When RUN_EN is
turned on, terminals
for external operation
signal became
effective
44 PID_OFF
The external
terminal stopping
PID enable
The signal
is sent, PID
calculation
stops at
once
