4.2 Basic Operation Procedures for Different Modes
4.2.1 Basic operation procedures for the PU mode (P.79=0 or 1 )
Steps Description
1
• Change the operation mode to PU mode, and the indicating lamp of will be lit up.
Note: 1. When P.79
=0, after the power is switched on or the inverter is reset, the inverter will
enter the external mode first.
2. For selecting and switching the operation modes, please refer to Section 4.1.
2
• Enter into the frequency setting mode, and write the target frequency into the memory.
Note: Please refer to Section 4.1.4 for the detailed setting procedures.
3
• Press
FWD
or
REV
to run the motor.
• At this time, the indicating lamp of
will flicker, indicating that the motor is
running. The operation panel then enters into the monitoring mode automatically. (P
lease refer
to P.110 in Chapter 5 for detailed descriptions.)
Note: 1. Please refer to Section 4.1.3 for the operating flow of the monitoring mode.
2. The frequency setting mode is valid while the motor is running, and thus the target frequency can be
changed to regulate the motor speed.
4
•
Press
STOP
RESET
and the motor will start to decelerate until it stops.
•
The indicating lamp of will stay on until the inverter stops outputting voltages.
4.2.2 Basic operation procedures for external mode ( , P.79=0 or 2)
Steps Description
1
• The indicating lamp of
will be lit up when changing the operation mode to the external
mode.
Note: 1. When P.79=0, press to switch to the operating mode
after the power is turned on or the inverter is
reset. The inverter will enter the external mode first, then press or to shift to PU mode.
2. When P.79=2, the inverter will always be at the external mode.
3. Please refer to Section 4.1 for selecting and switching the operation modes.
2
• Please refer to P.39 in Chapter 5 if the target f
requency is set by the input signal across terminal
4-5.
• Please refer to P.4 in Chapter 5 if the target frequency is set by multi-speed stage levels.
• Please refer to P.38 in Chapter 5 if the ta
rget frequency is set by the input signal across terminal
2-5.
• Please refer to P.82 in Chapter 5 if the target frequency is given by the pulse.
• Please refer to multi-function terminals P.80~P.84, P.86
in Chapter 5 if progr
ammable operating
mode is chosen.
