3.11 CXDI-50G Imaging Unit
Mobile DaRt Operation Manual
3-17
3.11 CXDI-50G Imaging Unit
CXDI-50G Imaging Unit
Fig. 3-12 CXDI-50G Imaging unit
TREAT THE IMAGING UNIT CAREFULLY!
Do not drop or hit anything with the imaging unit, or it might be damaged and
does not work anymore.
The imaging unit is equipped with four shock detectors. This detector is
normally white, and an excessive shock will cause it to change color. If the
shock detector changes color, there is a chance the imaging unit is damaged or
broken. Also, if the shock detector changes color, any damage incurred is
outside the scope of the device’s guarantee.
SHOCK DETECTOR
To Next Page
