Shinco SDP1731A User Manual

REF No. PART No. PART NAME REF No. PART No. PART NAME
R15 P11013
Resistor chip 10K
¡
C1 P31091 EEVMC1C470P
C2 P20035 Capacitor chip 1uF C2 P31100 Ceramic CAP 10uF/16V
C3 P20012 Capacitor chip 0.01uF C3 P31100 Ceramic CAP 10uF/16V
C4 P20015 Capacitor chip 0.1uF C4 P31100 Ceramic CAP 10uF/16V
C5 P20035 Capacitor chip 1uF C5 P31100 Ceramic CAP 10uF/16V
C6 P20014 Capacitor chip 47000pF C6 P31100 Ceramic CAP 10uF/16V
C7 P20006 Capacitor chip 100pF C7 P31100 Ceramic CAP 10uF/16V
C8 P20010 Capacitor chip 1500pF C8 P31100 Ceramic CAP 10uF/16V
C9 P20012 Capacitor chip 0.01uF C9 P31100 Ceramic CAP 10uF/16V
C11 P20043 Capacitor chip 3300pF C10 P31100 Ceramic CAP 10uF/16V
C14 P20031a GHM1038SL120J3K C11 P31100 Ceramic CAP 10uF/16V
C15 P20013 Capacitor chip 22000pF C12 P31091 EEVMC1C470P
C16 P20021 Capacitor chip 4.7uF CB1 P20015 Capacitor chip 0.1uF
C17 P20023 Capacitor chip 10uF CB2 P20015 Capacitor chip 0.1uF
C18 P20014 Capacitor chip 47000pF CB3 P20015 Capacitor chip 0.1uF
C20 P20028 Capacitor chip 220pF CB4 P20015 Capacitor chip 0.1uF
D1 P1557 DAN217T146 XS1 P6849 MOLEX-52437-3091
D2 P1557 DAN217T146 XS3 P60083 SM20B-SURS-TF SOCKET
Q1 P5750 MMST3904T146 XS4 P6981 MOLEX-53261-0490
Q2 P5706 DTC144EUAT106 XS6 P60083 SM20B-SURS-TF SOCKET
Q3 P5749 RK7002T116
Z1 P1558 UDZSTE-175.6B
Z2 P1558 UDZSTE-175.6B
Z3 P1558 UDZSTE-175.6B
U1 P90100 OZ960S
U2 P90102 SI5504DC
U3 P90102 SI5504DC
F1 a7276 K12 FUSE
CN1 P6981 MOLEX-53261-0490
XS1 P7045 BHS-2P
R1 P11052
Resistor chip 3K
¡
R2 P11014
Resistor chip 12K
¡
R3 P11000
Resistor chip 0
¡
R5 P11000
Resistor chip 0
¡
TRANSISTOR
CAPACITOR
RESISTOR
CAPACITOR
SOCKET
IC
OTHER
DVD1731T-AS IF PCB ASS'Y
