2.2.2 Parts List (SAL-1HP/2HP-UGP)
Table 2-1：Parts List (SAL-1HP/2HP-UGP)
No. Name Part No. No. Name Part No.
1 Anti-vibration pad YW03005000000 15
Filter barrel lid
assembly
-
2 Base BL26000202420 16 Controller holder BL26010241820
3
Lower welding block on
column
- 17 Main switch * YE10200300000
4 Standing post BL26000202920 18 Control box BL21000101920
5
Upper welding block on
column
- 19 Alarm light YE83305100200
6 Blower flange - 20 Filter barrel lid barrel YR10030000000
7 Air inlet pipe BL21000200320 21 Filter barrel lid -
8
Diaphragm valve
connection pipe
- 22 Air filter* YR50708000000
9
Vacuum breaking
diaphragm valve
BY20015000050 23 Star nut YW09051600000
High pressure pipe 1HP BM30031000150 24
Filter container seal
ring*
YR10708000100
10
High pressure pipe 2HP BM30042000050 25 Spring clip* YW02003000400
11 Clip YW02000200000 26 Acryl BH32070000050
12 Steel wired plastic pipe YR60157000000 27 Seal ring YR40000400000
13 Filter fixing bracket - 28
Iron sheet of 4-hole
sight glass
YW09000000400
14
Filter barrel base
fastener
- 29 Filter barrel BL26000203621
* means possible broken parts.
** means easy broken part. and spare backup is suggested.
Please confirm the version of manual before placing the purchase order to guarantee that the
item number of the spare part is in accordance with the real object.
