69(107)
Chart 2-24：Parts List of Electrical Components (SG-3060 230V)
NO. Symbol
Name Specification Part NO.
1 Q1 Gate circuit breaker 125A YE41161200000
2 Q2 Circuit breaker 10A YE40600300000
3 Q3 Circuit breaker 5A YE40603000000
4 K1 Contactor * 220V 50/60Hz YE00503500000
5 - Auxiliary contactor 1NC YE00592110100
6 K2 Contactor * 220V 50/60Hz YE00503500000
7 - Auxiliary contactor 1NC YE00592110100
8 - Auxiliary contactor 1NC YE00592110100
9 K3 Contactor * 220V 50/60Hz YE00503400000
10 - Auxiliary contactor 1NC YE00592110100
11 - Auxiliary contactor 1NC YE00592110100
12 K4 Contactor * 220V 50/60Hz YE00601521000
13 - Auxiliary contactor 1NO YE00691110000
14 K5 Contactor * 220V 50/60Hz YE00601521000
15 K6 Contactor * 220V 50/60Hz YE00504400000
16 - Auxiliary contactor 1NC YE00592110100
17 K7 Intermediate relay * 220VAC YE03270700000
18 K8 Safety relay * 220VAC YE04372100000
19 F1 Thermal overload relay * 20~25A YE01513600100
20 F2 Thermal overload relay * 2.2~3.2A YE01160220000
21 F3 Thermal overload relay * 1.8~2.5A YE01160180000
22 F11 Fuse ** 2P YE41032200000
23 - Fuse core ** 2A YE46002000100
24 X1 Terminal 35mm
2
YE61350040000
25 - - 35mm
2
PE YE61353500000
26 X2 Terminal 10mm
2
YE61100000000
27 - - 10mm
2
PE YE61103500000
28 X3 Terminal 2.5mm
2
YE61250040000
29 - - 2.5mm
2
PE YE61253500000
To Next Page
