No. Part No. Part Name Q’ty Remark
1 1080030003 Installation Plate 1
2 1080320807AC Base 1
3 1070020017AA Cross Fan 1
4 1070100010 Bearing Mount 1
5 211205977A Evaporator 1
6 1070251833AP Water Drainage Assembly 1
7 1070321035 Vertical Vane Assembly 2
8 1070251372AE Face Frame 1
9 1070321022AC Screw Cover 2
10 1070250106 Air Filter 2
11 1070252211 Display PCB Box 1
12 1090321196 Display PCB 1
13 210705001 Front Panel 1
14 1170120044 Power Supply Cord 1
15 1070251837AE Vane 1
16 1070110011 Drainage Hose 1
17 1070040004 Cable Clamp 1
18 210900789 Main PCB 1
19 1070320113 Electrical Box 1
20 1170020011 Vane Motor 1
21 1073010501 Sensor Holder 1
22 1170030047 Indoor Motor 1
23 1070320111 Indoor Motor Cover 1
24 1170240001 Transformer 1
25 1170230001 Indoor Sensor Assembly 1
26 1080320818AB In And Out Pipe Fixer 1
27 1090050298BU Remote Controller 1
28 1070060003 Remote Controller Supporter 1
29 1190060827ABQ Indoor Carton 1
30 211310246 Left Foaming 1
31 211310247 Right Foaming 1
Not shown in Explosion view
Indoor Unit- SSH-I076BE
Air Conditioner Service Manual
13
