No. Part No. Part Name Q’ty Remark
1 1071990038 Grille 1
Optional
2 1081990014 Top Cover 1
3 211201000 Condenser 1
4 1081990018 Outdoor Motor Supporter 1
5 1170040062 Outdoor Motor 1
6 1070030006A Propeller Fan 1
7 1081990011 Left Grille Supporter 1
8 1081990016 Front Plate 1
9 1071990044 Fan Guard 1
10 211201021 Compressor And It Accessories 1
11 1120110016 4-way Valve 1
12 211206398 4-way Valve Assembly 1
13 210800528 Base 1
14 1081990012 Right Plate 1
15 1120120025 Two-way Valve 1
16 1081990013 Valve Supporter 1
17 1120130039 Three-way Valve 1
18
1073521301
Electrical Box Cover 1
19 1070040001
Cable Clamp(φ6)
1
20 1070040002
Cable Clamp(φ7)
1
21 1170500131 Terminal 1
22 1170100031 Fan Motor Capacitor 1
23 1170100014 Compressor Capacitor 1
24 1080010002 Capacitor Strip 1
25 1081990010 Electrical Parts Box 1
26 211206477 Capillary Assembly 1
27 1081990019 Partition plate 1
28 211313638 Base Carton 1
29 211313639GD Cabinet Carton 1
30 211313637 Base Foaming 1
31 211313636 Cover Forming 1
Air Conditioner Service Manual
Outdoor Unit- SRH-I096BE
Not shown in the Explosion view.
18
To Next Page
