Shure Microflex MXV Series Manual

Shure Incorporated
23/100
•
•
Models
Microphone Type Battery Model
MXW1 bodypack
SB901AMXW6 boundary
MXW8 gooseneck base
MXW2 handheld
SB902
SB905*
* For MXW2 built after 12/2020
Networked Charging Station (NCS)
Slide the transmitter into the charging slot until it secures into place. The charge LEDs illuminate when the charge cycle begins.
Regardless of Group association or network connection, any microphone can recharge in any NCS.
Handheld, boundary and bodypack: use the main vertical slots in the recessed bays.
Gooseneck base: uses the top row's horizontal connectors. (Not included on two-channel chargers).
Charge Status LEDs
Each charger channel has a row of LEDs that illuminate to indicate the microphone battery charge level:
LED % Battery Charge
1
Flashing: <10%
Solid: >10%
