Important Note:
PDF versions of these instructions are available at:
http://shuttlesystems.com/pages/faq
!!
Assembly of the Shuttle MVP requires two people.
Keep in mind that the following images pertain to just one of the three
available Shuttle MVP models, your parts may appear slightly different than
those in the included images but, the required steps remain the"
same.
If there is any shipping damage please take a photo of the damage and "
email to support@shuttlesystems.com or call (800)334-5633.
Tools Needed:
7/16 inch socket or combination wrench "
1/2 inch socket or combination wrench "
9/16 inch socket or combination wrench"
Allen wrench (provided in Parts Bag)
Typical combination wrench set
Most of the pictures shown are from an MVP without
Towers to better show bolt placement.
