1. Remove the Kickplate Board. This can be done by unscrewing the 4 knurled knobs from
the back of the Kickplate Structure. (Pic 1.1)"
2. Remove the Carriage. This can be done by unscrewing the 4 Eyebolts and removing the 2
Knee Bumpers at the Head-End of the Rails. (Pic 1.2)"
3. Once the Kickplate Board and Carriage are removed, turn the Shuttle MVP on its side to
get access to the two feet at the Head-End Stand. This step is easier with two people.
4. Remove the two feet on the Head-End stand using a 1/2” socket and the included Allen
wrench in the Parts Bag. (Pic 1.4)"
5. Position and secure the Tower Base to the exposed bolt holes and tighten the two feet
back down. Once done flip the Machine upright and secure the Kickplate Board and
Carriage. (Pic 1.5)
