Shuttle MVP - Assembly of the MVP

Page 6
STEP 2
ATTACHING THE WINGS
ITEMS"
REQUIRED"
TOWER
WINGS"
PARTS BAG
1. Remove the top two bolts from the Head-End Stand and add the wings in alignment with
the now exposed bolt holes. (Pic 2.1)"
2. Using the hardware attached to the Wings, tighten down fully to the MVP Rails with the lock
nuts facing outwards. (Pic 2.2)"
3. Place the nut caps now exposed on the outside of the machine."
2.1"
2.2"
2.3
