SP-110-SS30 3 10/25/2011
Basic Operation – Non Rudder Feedback Version
Switch on power to autopilot. Display shows boat heading - example H123. MANUAL
light (LED) will be on. Steer vessel to course.
To engage autopilot for automatic steering:
Press AUTO. Display will show heading for autopilot to steer - example A123. AUTO
light (LED) will be on.
Press ◄ to adjust course to port. Press ► to adjust course to starboard
To disengage autopilot for manual steering:
Press AUTO. Display will show boat heading. MANUAL light on
To set rudder response (rudder angle ratio)
Press MODE. Display will show a number - example r 05.
Press ► to increase rudder setting. Press ◄ to decrease setting.
3 seconds after adjustment pilot will return display to normal.
To switch LCD back light on or off.
Press MODE MODE
Press ◄ or ► to turn light on. Press ◄ or ► again to turn light off.
To return pilot to normal continue pressing MODE.
Waypoint Steering
Note: Before engaging waypoint steering mode, a route or destination must
be programmed and selected in the GPS plotter for the autopilot to follow
To engage waypoint steering:
Press both AUTO and MODE buttons together. GPS light will be on.
The autopilot will lock on to “course to steer” as requested by the GPS plotter.
Displays shows bearing to waypoint (BTW).
If no GPS data is received by the SP-110, “NO GPS DATA” alarm will function. Both
GPS and ALARM lights will flash on and off.
To disengage GPS mode:
Press AUTO button. Pilot will return to MANUAL operation.
.
