SIC CFR Series - Page 53

Manuale di Installazione e Manutenzione Recuperatori di Calore - Heat Recovery Units Installation, use and maintenance manual
pag. 53
MODELLO
MODEL
POSIZIONE VISTA ESPLOSA
EXPLODED VIEW POSITION
CODICE SIC
SIC CODE
33
20 Scheda elettrica / Panel control board ND/NA
21 Scatola elettrica / Electric box
ME3000GWGW44006
CP02ASCATOLAEL
(1)
30 Ventilatore / Fan
VTD2E133DM021175
VTD3G0146EC00300
(1)
33 Filtro standard / Standard Filter CFPZ0445275100
35 Scatola rotore / Rotary exchanger box CP02A00PR2RR0330
36 Recuperatore rotativo / Rotary exchanger SR0500100015AAC0
38 Maniglia / Handle MR200190235010
39 Coperchio rotore / Rotary exchanger cover CP02A00PR1RR0330
41 Cinghia di trasmissione / Transmission belt CGCIRSALD0330801
43 Riduttore / Gear head RI02501800000000
44 Motore / Induction motor MI025M230FU00001
45 Puleggia / Pulley PV0HE01100000000
13
(2)
Batteria SBFR / SBFR water coil BT252WCZ028004N0
10
(2)
Resistenza elettrica / Electric heater BE2300A0000015
55
20 Scheda elettrica / Panel control board ND/NA
21 Scatola elettrica / Electric box
ME3000GWGW44006
CP02ASCATOLAEL
(1)
30 Ventilatore / Fan
VTD2E133DM021175
VTD3G0146EC00300
(1)
33 Filtro standard / Standard Filter CFPZ0445275100
35 Scatola rotore / Rotary exchanger box CP02A00PR2RR0330
36 Recuperatore rotativo / Rotary exchanger SR0500100015AAC0
38 Maniglia / Handle MR200190235010
39 Coperchio rotore / Rotary exchanger cover CP02A00PR1RR0330
41 Cinghia di trasmissione / Transmission belt CGCIRSALD0330801
43 Riduttore / Gear head RI02501800000000
44 Motore / Induction motor MI025M230FU00001
45 Puleggia / Pulley PV0HE01100000000
13
(2)
Batteria SBFR / SBFR water coil BT252WCZ028004N0
10
(2)
Resistenza elettrica / Electric heater BE2300A0000003
110
20 Scheda elettrica / Panel control board ME1000940343.1
21 Scatola elettrica / Electric box CP02ASCATOLAEL
30 Ventilatore / Fan
VTDDM07074300147
VTDDM0707EC00310
(1)
33 Filtro standard / Standard Filter CFPZ0275555100
35 Scatola rotore / Rotary exchanger box CP02A00PR2RR1100
36 Recuperatore rotativo / Rotary exchanger SR0600100015AAC0
38 Maniglia / Handle MR200190235010
39 Coperchio rotore / Rotary exchanger cover CP02A00PR1RR1100
41 Cinghia di trasmissione / Transmission belt CGCIRSALD1100801
43 Riduttore / Gear head RI02501800000000
44 Motore / Induction motor MI025M230FU00001
45 Puleggia / Pulley PV0HE01100000000
13
(2)
Batteria SBFR / SBFR water coil BT252WD2032006NO
10
(2)
Resistenza elettrica / Electric heater BE4000AM000003
175
20 Scheda elettrica / Panel control board ME1000940343.1
21 Scatola elettrica / Electric box CP02ASCATOLAEL
30 Ventilatore / Fan
VTDDM09074300350
VTDDM0907EC00560
(1)
33 Filtro standard / Standard Filter CFPZ0750360100
35 Scatola rotore / Rotary exchanger box CP02A00PR2RR1750
36 Recuperatore rotativo / Rotary exchanger SR0800100015AAC0
38 Maniglia / Handle MR200190235010
39 Coperchio rotore / Rotary exchanger cover CP02A00PR1RR1750
41 Cinghia di trasmissione / Transmission belt CGCIRSALD1750801
43 Riduttore / Gear head RI02501800000000
44 Motore / Induction motor MI025M230FU00001
45 Puleggia / Pulley PV0HE01100000000
13
(2)
Batteria SBFR / SBFR water coil BT252WD8032006NO
10
(2)
Resistenza elettrica / Electric heater BE4000A0000006
220
20 Scheda elettrica / Panel control board ME1000940343.1
21 Scatola elettrica / Electric box CP02ASCATOLAEL
30 Ventilatore / Fan
VTDDM09074300350
VTDDM0907EC00560
(1)
33 Filtro standard / Standard Filter CFPZ0750360100
35 Scatola rotore / Rotary exchanger box CP02A00PR2RR2200
36 Recuperatore rotativo / Rotary exchanger SR0800100015AAC0
38 Maniglia / Handle MR200190235010
39 Coperchio rotore / Rotary exchanger cover CP02A00PR1RR2200
41 Cinghia di trasmissione / Transmission belt CGCIRSALD2200801
43 Riduttore / Gear head RI02501800000000
44 Motore / Induction motor MI025M230FU00001
45 Puleggia / Pulley PV0HE01100000000
13
(2)
Batteria SBFR / SBFR water coil BT252WDB035506NO
10
(2)
Resistenza elettrica / Electric heater BE4000A0000006
MODELLO
MODEL
POSIZIONE VISTA ESPLOSA
EXPLODED VIEW POSITION
CODICE SIC
SIC CODE
255
20 Scheda elettrica / Panel control board ME1000940343.1
21 Scatola elettrica / Electric box CP02ASCATOLAEL
30 Ventilatore / Fan
VTDDM09094300350
VTDDM0909EC00560
(1)
33 Filtro standard / Standard Filter CFPZ0965550100
35 Scatola rotore / Rotary exchanger box CP02A00PR2RR3200
36 Recuperatore rotativo / Rotary exchanger SR1000100015AAC0
38 Maniglia / Handle MR200190235010
39 Coperchio rotore / Rotary exchanger cover CP02A00PR1RR3200
41 Cinghia di trasmissione / Transmission belt CGCIRSALD25508
43 Riduttore / Gear head RI04001800000000
44 Motore / Induction motor MI040M230FU00001
45 Puleggia / Pulley PV0HE016000000
13
(2)
Batteria SBFR / SBFR water coil BT252WDC050008NO
10
(2)
Resistenza elettrica / Electric heater BE4000A0000006
320
20 Scheda elettrica / Panel control board ME1000940343.1
21 Scatola elettrica / Electric box CP02ASCATOLAEL
30 Ventilatore / Fan
VTDDM10104300550
VTDDM1010EC00560
(1)
33 Filtro standard / Standard Filter CFPZ0965550100
35 Scatola rotore / Rotary exchanger box CP02A00PR2RR3200
36 Recuperatore rotativo / Rotary exchanger SR1000100015AAC0
38 Maniglia / Handle MR200190235010
39 Coperchio rotore / Rotary exchanger cover CP02A00PR1RR3200
41 Cinghia di trasmissione / Transmission belt CGCIRSALD25508
43 Riduttore / Gear head RI04001800000000
44 Motore / Induction motor MI040M230FU00001
45 Puleggia / Pulley PV0HE016000000
13
(2)
Batteria SBFR / SBFR water coil BT252WDC050008NO
10
(2)
Resistenza elettrica / Electric heater BE4000A0000006
410
20 Scheda elettrica / Panel control board QE100530ST0C2VT0
21
Quadro elettrico / Panel control board QE100530ST0C2VT0
Scatola elettrica / Electric box CP02ASCATOLAEL
30 Ventilatore / Fan
VTDDM10104200750
VTDDM1010EC00920
(1)
33 Filtro standard / Standard Filter CFPZ0965550100
35 Scatola rotore / Rotary exchanger box CP02A00PR2RR3200
36 Recuperatore rotativo / Rotary exchanger SR1000100015AAC0
38 Maniglia / Handle MR200190235010
39 Coperchio rotore / Rotary exchanger cover CP02A00PR1RR3200
41 Cinghia di trasmissione / Transmission belt CGCIRSALD25508
43 Riduttore / Gear head RI04001800000000
44 Motore / Induction motor MI040M230FU00001
45 Puleggia / Pulley PV0HE016000000
13
(2)
Batteria SBFR / SBFR water coil BT252WDC055010NO
10
(2)
Resistenza elettrica / Electric heater BE4000A0000006
530
20 Scheda elettrica / Panel control board QE100530ST0C2VT0
21
Quadro elettrico / Panel control board QE100530ST0C2VT0
Scatola elettrica / Electric box CP02ASCATOLAEL
30 Ventilatore / Fan
VTDDM10104200800
VTDDM1010EC00920
(1)
33 Filtro standard / Standard Filter CF0P411656500100
35 Scatola rotore / Rotary exchanger box CP02A00PR2RR5300
36 Recuperatore rotativo / Rotary exchanger SR1100100015AAC0
38 Maniglia / Handle MR200190235010
39 Coperchio rotore / Rotary exchanger cover CP02A00PR1RR5300
41 Cinghia di trasmissione / Transmission belt CGCIRSALD0400000
43 Riduttore / Gear head RI04001800000000
44 Motore / Induction motor MI040M230FU00001
45 Puleggia / Pulley PV0HE016000000
13
(2)
Batteria SBFR / SBFR water coil BT252WDJ060016NO
10
(2)
Resistenza elettrica / Electric heater BE4000A0000006
