Part No. Drawing No. Description Q'ty
.1-46 XN3A0206 Motor connect plate 1
.1-47
GB273.2-87-单排 7/70
Thrust ball bearing single 7/70 2
.1-48 XN3A0209 Worm shaft 1
.1-49 XN3A0203 Worm eccentric sleeve 1
.1-50 X3C021100 Tighten the top rod 1
.1-51 GB 119-86 - A 3 x 10 Round pin A3*10 1
.1-52 GB 301-84 - 8106 Thrust ball bearing single 8106 1
.1-53 GB 278-89 - 80106 Deep groove ball bearing 80106 1
.1-54 X3C0209 Up washer 1
.1-55 GB 810-76 Slotted round nut 2
.1-56 GB 70-85 - M4 x 12 Hexagon round head cap screw M4*12 6
.1-57 GB 278-89 - 80107 Deep groove ball bearing 80107 1
.1-58 GB 893.1 - 62 Check ring 62 1
.1-59 GB 894.1 - 35 Check ring 35 1
.1-60 GB 70-85 - M5 x 16 Hexagon round head cap screw M5*16 4
.1-61 X3C0212 Spindle MT3 1
.1-62
HTD-M5 385（77 齿）
Timing belt 1
.1-63 GB 97.1-85 - 6 Washer 6 4
.1-64 GB 70-85 - M6 x 14 Hexagon round head cap screw M6*14 4
.1-65 YE023003 Φ6 Magnet steel 2
.1-66 GB 879-86 - 3 x 8 Spring round pin 3*8 1
.1-67 X3C0237 Assist small handle 1
.1-68 GB 119-86 - A 3 x 14 Round pin A3*14 1
.1-69 GB 819-85 - M3x10 Cross recessed counter head screws H M3*10 2
.1-70 XN3A0220 Washer 1
.1-71 XN3A0213 Spindle sleeve position shaft 1
.1-72 GB 894.1-86 20 Check ring 20 2
.1-73 XN3A0214 Display fixed bracket 1
.1-74 XN3A0222 Adjust washer 1
.1-76 GB 70-85 - M10 x 16 Hexagon round head cap screw M10*16 1
.1-77 XN3A0202 Bevel wedge 1
.1-78 XN3A0223 Wedge screw 2
.1-79 XN3A0226 Sleeve limited washer 1
.1-80 ZYT-750 750W DC motor 1
.1-81 GB 894.1 - 12 Check ring 12 1
.1-82 GB1096-79 4x25 Parallel key 4*25 1
.1-83 GB 70-85 - M4 x 6 Hexagon round head cap screw M4*6 2
.1-84 GB 819-85 - M6x14 Cross recessed counter head screws H M6*14 4
.1-85 XN3A0225 Probe bracket 1
.1-86 XN3A0211 Attechment bracket 1
1-87 GB 70-85 M4 x 40 Hexagon round head cap screw M4*40 4
.1-88 GB 5781-86 - M5x12 Hexagon headed bolt M5*12 3
1-89 XN3A02500 Probe subassembly 1
1-90 φ22 Plug 2
