Part No. Drawing No. Description Q'ty
.2-48 GB273.2-87-7/70 Thrust ball bearing single 7/70 2
.2-49 XN3A0203 Worm eccentric sleeve 1
.2-50 XN3A0209 Worm shaft 1
.2-51
HTD-M5 385（77T）
Timing belt 1
.2-52 GB 119-86 - A 3 x 10 Round pin A3*10 1
.2-53 GB 819-85 - M5x25 Cross recessed counter head screws M5*25 1
.2-54 GB 97.1-85 - 6 Washer 6 4
.2-55 GB 70-85 - M6 x 14 Hexagon socket head cap screw M6*14 4
.2-56 GB 879-86 - 3 x 8 Spring round pin 3*8 1
.2-57 GB 818-85 - M4 x 6 Cross recessed small head screws M4*6 4
.2-58 XN3A0224 Locking small shaft 1
.2-59 GB308-89 - 8 Ball 8 3
.2-60 GB 119-86 - A 3 x 14 Round pin A3*14 1
.2-61 X3C0237 Assist small handle 1
.2-62 XN3A0211 Attachment bracket 1
.2-64 GB 819-85 - M3x10 Cross recessed counter head screws M3*12 2
.2-65 XN3A0214 Display fixed bracket 1
.2-67 XN3A0220 Washer 1
.2-68 XN3A0213 Spindle sleeve position shaft 1
.2-69 XN3A0222 Adjust washer 1
.2-70 XN3A0223 Wedge screw 2
.2-71 GB 70-85 - M10 x 16 Hexagon socket head cap screw M10*16 1
.2-72 XN3A0226 Sleeve limit washer 1
.2-73 XN3A0221 Shaft gear right support flange 1
.2-74 XN3A0212 Handle seat 1
.2-75 XN3A0219 Motor timing pulley 1
.2-76 ZYT-750 750W DC motor 1
.2-77 XN3A0206 Motor connect plate 1
.2-78 GB 819-85 - M6x14 Cross recessed counter head screws M6*14 4
.2-79 GB 894.1 - 12 Check ring 12 1
.2-80 GB1096-79 4x25 Parallel key 4*25 1
.2-82 XN3A0225 Probe bracket 1
.2-83 GB 70-85 - M4 x 6 Hexagon socket head cap screw M4*6 2
.2-84 RSD-27 Probe 1
.2-85 X30252 Handle lever 3
.2-86 X20237 Long handle sleeve 3
.2-87 XN3A0217 Tighten the top rod 1
2-88 GB 70-85 M4 x 40 Hexagon socket head cap screw M4*40 4
2-89 YE023005 Ø4x2magnet 1
2-90 XN3A02500 Probe subassemply 1
2-91 YE023003 Ø6 magnetic steel 2
2-92 GB 79-85 - M6 x 12 Set screw M6*12 1
2-93 GB 5781-86 - M5x12 Hexagon headed bolt M5*12 3
2-94 φ22 End cap 2
2-95 GB 77-85 - M6 x 8 Inner six angle locking screws M6*8 1
2-96 XN3A0216 Eccentric sleeve locking block 1
