Parts list (3) --- note: The no. With “*” means the part showing in metric.

Part No. Drawing No. Description Q'ty

.3-1 XN3A0901 Column 1

.3-2* XN3A0903A Metric rise and down leadscrew 1

.3-3* XN3A0908A Metric rise and down locking nut 1

.3-4* XN3A0907A Metric rise and down leadscrew nut 1

.3-5 XN3A0904 Column nut support 1

.3-6 XN3A0911 Leadscrew support 1

.3-7 GB 118-86 - 6 x 16 Taper pins with internal thread 6*16 2

.3-8 GB 70-85 - M6 x 12 Hexagon socket head cap screw M6*12 2

.3-9 XN3A0910 Rise and down support seat 1

.3-10 C2A0307 Handle 1

.3-11 GB 6172-86 M8 Hex nut M8 1

.3-12 X3111800 Handle wheel 1

.3-13 X31145 Spring piece 1

.3-14* XN3A0909A Metric rise and down scale dial 1

.3-15 GB 879-86 - 3 x 20 Spring round pin 3*20 1

.3-16 GB/T 276-94 - 6001 Deep groove ball bearing 6001 4

.3-17 GB 65-85x55 Slotted large cheese head screws 85*55 1

.3-18 GB 889-86 M8 Hex locking nut M8 1

.3-19 GB1096-79 4x16 Parallet key 4*16 1

.3-20 XN3A0902 Rise and down shaft 1

.3-21 GB 879-86 - 3 x 16 Spring round pin 3*16 1

.3-22 GB 70-85 - M5 x 30 Hexagon socket head cap screw M5*20 4

.3-23 GB 5781-86 - M5x16 Hexagon headed bolt M5*16 3

.3-24 GB 77-85 - M6 x 10 Inner six angle locking screws-flast end M6*10 1

.3-25 XN3A0912 Locking nut 4

.3-26 XN3A0914 Big bevel gear wheel 1

.3-27 XN3A0913 Small bevel gear wheel 1

.3-28 GB 78-85 - M5 x 8 Inner six angle locking screws-cone end M5*8 1

.3-29 GB 78-85 - M5 x 5 Inner six angle locking screws-cone end M5*5 1

.3-30 GB 5780-86 - M10x40 Hexagon headed bolt M10*40 4

.3-31 GB 97.1-85 - 10 Washer 10 4

.3-32 GB 859-87 - 10 Spring washer 10 4

.3-33 GB 118-86 - 6 x 24 Taper pins with internal thread 6*24 2

.3-34 GB 97.1-85 - 8 Washer 8 1

.3-35 GB 70-85 - M8 x 30 Hexagon socket head cap screw M8*30 2
