17. Technical specifications
Specification for a MHS400 smart
Supply voltage scheme A
120–230 V∼, 22 W
Supply voltage scheme C
120–230 V∼, 48 W
Device operating voltage
(power supply integrated in the slide drive)
24 V DC
Max. displacement force during slide operation
Approx. 50 N (depending on sash weight and friction)
Max. torque at square
Approx. 25 Nm
Traverse speed
Approx. 150 mm/sec.
Operating time of lift drive HA
Approx. 7 sec.
Temperature range
–5°C to 50°C
Jam protection Electronic overload cut-off device (current limiter in accor-
dance with standard)
Protection class IP20 for dry locations
Connection to AC mains power supply (at factory)
Europlug, cable length 5 m
Connection to AC mains power supply (at installation site)
(concealed cable channel)
5 x 1.5 mm² cable
(all-pole safety isolation required)
Connecting clamps
For a max. supply-line cross-section of 2.5 mm²
18. Accessories
Material description
Material no.
Jig catch GABB0010-0E5010
Jig through hole GABB0020-0E5010
Rose lock GZRS0010-096010 (white, RAL 9003)
GZRS0010-025010 (silver, RAL 9006)
Rose lock cover GZRA0010-096010 (white, RAL 9003)
GZRA0010-025010 (silver, RAL 9006)
Infrared remote control
GZFB0020-025010
Light curtain (inside/outside) Available from CEDES GmbH
Elzmatten 6, 79365 Reinhausen, Germany
