Commissioning
3.4 Configuring the drive components
Connection of the SINAMICS S120 to the Technology CPU
40 Product Information, 09/2011, A5E00480378-04
Configuring with Active Line Module (ALM)
1. In S7T Config, open the SINAMICS S120_CU320 folder, and double-click the
"Configure drive unit" entry or the drive.
2. First create the control unit, and the option modules. If you are using the TB30 terminal
board, select it from the drop-down list, and click the "Next" button to confirm the setting.
