Information and Communication Products
Communication Devices
V1.2 Page 23 of 34 ICP CD ST
D. Schnoor
8/99
7.4.2.3 Special Tools
None
7.4.2.4 Working materials
Desolder Wick / Braid
Solder
7.4.3 Drawings
Figure 2: C25 Display Connector (X3) and C2588 Display Connector (X2) Placement (Top View)
Figure 1: C25 Board Display Connector Side
