Installing
3.4 Mounting the Power Modules
Power Module PM240-2
Hardware Installation Manual, 01/2020, A5E33294624B AL
41
3.4.5 Hoisting gear FSD ... FSG
Power Module weights:
200 V converter (Page 79)
400 V converter (Page 89)
690 V converter (Page 101)
Hoisting gear - Built-in devices
Use crane lifting lugs and the appropriate hoisting gear when mounting built-in devices.
Hoisting gear - PT devices
Use the hoisting gear shown below when mounting the Power Modules
Alternatively, you have the option of attaching mounting grips onto the Power Module.
Mounting grips for PT Power Modules (Page 122).
