Accessories
7.1 Reactor and filter
Power Module PM240
88 Hardware Installation Manual, 07/2009, A5E00807525B AD
Suitable for Power Module with rated power (HO) of
0.37 kW ... 1.5 kW 2.2 kW ... 4 kW 5.5 kW ... 11 kW
Feature
FSA FSB FSC
Overall dimensions
Width
Height
Depth
73 mm
200 mm
42.5 mm
153 mm
296 mm
50 mm
190 mm
362 mm
55 mm
Fixing dimensions
Width
Height
56 mm
187 mm
120 mm
200 mm
156 mm
232 mm
Fixing screw 4 × M4 4 × M5
Weight 0.5 kg 1.5 kg 2.3 kg
Possible as base
component
yes
