Siemens CU240B-2 Operating Instructions

Article No. with filter, C2
Article No. with filter, C1
6SL3223-0DE23-0AG1
6SL3223-0DE23-0BG1
Fuse according to IEC
Fuse according to UL, class J
3NA3803
10 A
Power loss 0.12 kW
Required cooling air flow 7 l/s
Weight 4.3 kg
Table 10-4 PM230, IP55, Frame Size B, 3-ph. AC 380 V … 480 V
Article No. with filter, C2
Article No. with filter, C1
6SL3223-0DE24-0AG1
6SL3223-0DE24-0BG1
6SL3223-0DE25-5AG1
6SL3223-0DE25-5BG1
6SL3223-0DE27-5AG1
6SL3223-0DE27-5BG1
LO base load power 4 kW 5.5 kW 7.5 kW
LO base load input current 10.5 A 13.6 A 18.6 A
LO base load output current 10.2 A 13.2 A 18 A
HO base load power 3 kW 4 kW 5.5 kW
HO base load input current 8.0 A 10.5 A 13.6 A
HO base load output current 7.7 A 10.2 A 13.2 A
Fuse according to IEC
Fuse according to UL, class J
3NA3805
16 A
3NA3807
25 A
3NA3810
35 A
Power loss 0.14 kW 0.18 kW 0.24 kW
Required cooling air flow 9 l/s 9 l/s 9 l/s
Weight 6.3 kg 6.3 kg 6.3 kg
Table 10-5 PM230, IP55, Frame Size C, 3-ph. AC 380 V … 480 V
Article No. with filter, C2
Article No. with filter, C1
6SL3223-0DE31-1AG1
6SL3223-0DE31-1BG1
6SL3223-0DE31-5AG1
6SL3223-0DE31-5BG1
6SL3223-0DE31-8AG1
---
LO base load power 11 kW 15 kW 18.5 kW
LO base load input current 26.9 A 33.1 A 39.2 A
LO base load output current 26 A 32 A 38 A
HO base load power 7.5 kW 11 kW 15 kW
HO base load input current 18.6 A 26.9 A 33.1 A
HO base load output current 18 A 26 A 32 A
Fuse according to IEC
Fuse according to UL, class J
3NA3814
40 A
3NA3820
50 A
3NA3820
50 A
Power loss 0.32 kW 0.39 kW 0.46 kW
Required cooling air flow 20 l/s 20 l/s 20 l/s
Weight 9.5 kg 9.5 kg 9.5 kg
Technical data
10.3 Technical data, PM230 Power Module
Converter with the CU230P-2 Control Units
Operating Instructions, 09/2017, FW V4.7 SP9, A5E34257946B AE 443
