Table 10-6 PM230, IP55, Frame Size D, 3-ph. AC 380 V … 480 V
Article No. with filter, C2
Article No. with filter, C1
- 6SL3223-0DE31-8BG0 6SL3223-0DE32-2AG0
6SL3223-0DE32-2BG0
6SL3223-0DE33-0AG0
6SL3223-0DE33-0BG0
LO base load power 18.5 kW 22 kW 30 kW
LO base load input current 39.2 A 42 A 56 A
LO base load output current 38 A 45 A 60 A
HO base load power 15 kW 18.5 kW 22 kW
HO base load input current 33.1 A 36 A 42 A
HO base load output current 32 A 38 A 45 A
Fuse according to IEC
Fuse according to UL, class J
3NA3820
50 A
3NA3822
63 A
3NA3824
80 A
Power loss 0.46 kW 0.52 kW 0.68 kW
Required cooling air flow 20 l/s 39 l/s 39 l/s
Weight 30.2 kg 30.2 kg 30.2 kg
Table 10-7 PM230, IP55, Frame Size E, 3-ph. AC 380 V … 480 V
Article No. with filter, C2
Article No. with filter, C1
6SL3223-0DE33-7AG0
6SL3223-0DE33-7BG0
6SL3223-0DE34-5AG0
6SL3223-0DE34-5BG0
LO base load power 37 kW 45 kW
LO base load input current 70 A 84 A
LO base load output current 75 A 90 A
HO base load power 30 kW 37 kW
HO base load input current 56 A 70 A
HO base load output current 60 A 75 A
Fuse according to IEC
Fuse according to UL, class J
3NA3830
100 A
3NA3832
125 A
Power loss 0.99 kW 1.2 kW
Required cooling air flow 39 l/s 39 l/s
Weight 35.8 kg 35.8 kg
Table 10-8 PM230, IP55, Frame size F, 3-ph. AC 380 V … 480 V
Article No. with filter, C2
Article No. with filter, C1
6SL3223-0DE35-5AG0
6SL3223-0DE35-5BG0
6SL3223-0DE37-5AG0
6SL3223-0DE37-5BG0
6SL3223-0DE38-8AG0
6SL3223-0DE38-8BG0
LO base load power 55 kW 75 kW 90 kW
LO base load input current 102 A 135 A 166 A
LO base load output current 110 A 145 A 178 A
HO base load power 45 kW 55 kW 75 kW
HO base load input current 84 A 102 A 135 A
HO base load output current 90 A 110 A 145 A
Fuse according to IEC
Fuse according to UL, class J
3NA3836
160 A
3NA3140
200 A
3NA3144
250 A
Technical data
10.3 Technical data, PM230 Power Module
Converter with the CU230P-2 Control Units
444 Operating Instructions, 09/2017, FW V4.7 SP9, A5E34257946B AE
