Siemens DS40022 - Page 9

I.
1 2
l
G1
G1
c
k
h
b
a
e
30°
30°
45°
G 1/2
19 mm
12
3
4
5
6
7
8
9
10
11
II.
III.
DS20022 DS30022 DS40022
Ø a
[mm] 550 650 700
b
[mm] 690 790 840
c
[mm] 340 365 375
Ø e
[mm] 430 490 540
l
[mm] 75 75 75
k
[mm] 1 035 1 040 1 160
h ± 10
[mm] 1 545 1 560 1 730
