en Installation instructions
26
1.
Make the cut-out in the fitted unit.
If you already have the cut-out for a previous model
of the same brand, you can continue using this.
2.
Make the cut-out for the exhaust pipe.
Preparing the appliance
1.
Remove the grease filters.
To avoid causing damage, do not bend the grease
filters.
2.
Remove the panel. To do this, press the two latch-
ing mechanisms at the same time
⁠ and remove
the panel ⁠.
3.
Fit the one-way flaps on the air outlet and click them
into place.
Note:If the fitted unit is no longer accessible after the
appliance is installed, remove the side locking mechan-
ism. To do this, undo the fastening screws and secure
these to the appliance's housing.
Installing the appliance
1.
ATTENTION!
If you already have a cut-out for a previous model of
the same brand, the latching mechanism does not
engage.
▶ Secure the appliance so that it does not fall
down and become damaged.
Place the appliance in the cut-out
⁠.
New cut-out
Cut-out for a previous model
2.
Tighten the fastening screws ⁠.
If you are using a cut-out for a previous model, you
may not be able to use the side screws ⁠.
