173/219
Building Technologies Basic Documentation LMV27... CC1P7541en
26 Parameter level 17.12.2018
>3 s
P
Vh
mi n
s%
Bild 124/0707
>3 s
If it is not only the current curvepoint that shall be changed, but all other curvepoints in the direction of
travel as well, a new straight line from the current curvepoint to P9 (press
) or P1 (press ) can
be calculated by a long push on
or .
Display CALC
Example of presentation
)
P5 down to P1
Keep
depressed for >3 s
P5 up to P9
Keep
depressed for >3 s
CALC -
CALC +
Figure 83: Changing several curvepoints
Note
Due to interpolation, a number of curvepoints change. To be able to make a
check on the burner itself, the changed curvepoints must be approached in
the warm settings. If these curvepoints have not yet been completely
approached, OFF UPr appears on the normal display of the AZL2.
