Siemens LOGO! 230 RC - 6 Technical data

105
LOGO! manual
EWA 4NEB 712 6006-02
6 Technical data
General technical data
Criterion Complies with Values
Dimensions W×H×D
in mm
Weight
72 x 90 x 55
with installation mechanism:
72 x 90 x 59
approx. 190 g
Installation on 35 mm DIN rail
Width of 4 modules
Ambient climatic conditions
Ambient temperature Cold: IEC 68-2-1
°Horizontal installation
Vertical installation
Heat:
IEC 68-2-2
*
0 to 55
°
C
0 to 55 °C
Storage/transport 40 °C to + 70 °C
Relative humidity IEC 68-2-30 From 5 to 95%
no condensation
Atmospheric pressure From 795 to 1080 hPa
Pollutants IEC 68-2-42
IEC 68-2-43
SO
s
10 cm
3
/m
3
, 4 days
H
s
S 1 cm
3
/m
3
, 4 days
Ambient mechanical conditions
Protection type IP 20
Vibrations IEC 68-2-6 10 to 57 Hz (constant ampli-
tude 0.15 mm)
57 to 150 Hz (constant ac-
celeration 2 g)
Shock IEC 68-2-27 18 shocks
(half-sine 15g/11ms)
Drop IEC 68-2-31 Drop height 50 mm
Free fall (packaged) IEC 68-2-32 1 m
*
IEC 68 includes VDE 0631
