Siemens Milltronics BW500/L - Linearization Parameters (P390 - P392)

Parameters
12.6 Linearization Parameters (P390 - P392)
BW500 and BW500/L
172 Operating Instructions, 12/2016, A5E33482052-AD
12.6
Linearization Parameters (P390 - P392)
These parameters are used to compensate for non-linear response of the weighing system to
the BW500 and BW500/L. Refer to
Linearization for execution, and example on the use of these
parameters.
Note
In the case of multispan op
eration, the linearizer is applied to all spans.
12.6.1
P390 Linearizer
Enables or disables the linearization function.
Entry
:
0 = OFF f
1 = ON
12.6.2
P391 Linearizer Load Points
Enters the load values, in units of P017, for the point selected, points 1 to 5 (P391-01 to -05) ( f =
0.00, 150 % max.)
12.6.3
P392 Linearizer Compensation %
Enters the compensation value, in percent, for the point selected, point 1 to 5 (P392-01 to −05) ( f
= 0.00), range is -150 to 150 %.
12.6.4
P398-01 Moisture Content
Factors out moisture component of load, rate and total for all multispans selected. The factored
values are meant to report the dry mean values of the material being conveyed (
f = 0.00)
Enter the moisture content in % weight or mA Input Value
1)
.
1)
BW500/L will allow manual entry of a moisture content.
12.6.5
P398-02 Moisture Content
Allows moisture content P398-01 to be scaled to maximum value.
Enter the moisture content in % weight (maximum value 20 mA)
Note
Not available with BW500/L.
