Siemens Milltronics BW500/L - P621 Ma Zero Dropout; P631 Totalizer Resolution

Parameters
12.9 Totalization (P619 - P648)
BW500 and BW500/L
Operating Instructions, 12/2016, A5E33482052-AD
179
12.9.3
P621 mA Zero Dropout
Activates the limit as defined in P619 ’Totalling Dropout’, below which, the analog output, with
respect to rate and load only, is set to 0.0.
Note
•
Valid only if P201 = 1 or 2
•
BW500 has three mA outputs, BW500/L has one
12.9.4
P631 Totalizer Resolution
This parameter sets the resolution of the totalizer selected.
Totalizers are:
-01 = totalizer 1
-02 = totalizer 2
-03 = verification totalizer
-04 = material test totalizer
-05 = batch totalizer
1)
Entry:
1 = 0.001 (one thousandth)
2 = 0.01 (one hundredth)
3 = 0.1 (one tenth)
4 = 1 (unit)
f
5 = 10 (x ten)
6 = 100 (x hundred)
7 = 1000 (x thousand)
1)
Not available with the BW500/L
