Siemens RDE10.1DHW User Manual

Safety class II to EN 60730
Pollution class normal
Degree of protection of housing IP30 to EN 60529
Connection terminals for solid wires or prepared stranded wires.
2 x 1.5 mm
2
or 1 x 2.5 mm
2
(min. 0.5 mm
2
)
Weight 0.21 kg
Color of housing front white, NCS S 0502-G (RAL 9003)
General
Connection diagram
L
RDE10.1DHW
Q12 Q14
Nx
Lx
(inverse
of Q14)
L
Y1
Y2
Q22
Q24
(inverse
of Q24)
3038A02
3V
Lx - Nx AC 24...250 V / max. 5 (2) A
Legend
Y1 Heating valve or wall-hung boiler
Y2 DHW heating equipment
Application examples
T
T
F1
F2
N1
M1
Y2
3033S01
T
DHW
T
F1
F2
N1
M1
Y2
3033S02
T T
DHW
Room temperature controller with direct
control of a gas-fired wall-hung boiler and
independent control of DHW
Room temperature controller with direct control
of a gas-fired floor-standing boiler and
independent control of DHW
7/8
Building Technologies Room temperature controller RDE10.1DHW CE1N3038en
HVAC Products 20.10.2005
