• Remove the protective cover (9).
• Unscrew the lower hinge pin (10) and fix it
on the opposite side.
• Fit the lower compartment door (7) without
forgetting the separator (11), and screw the
centre hinge on.
• Fit the upper compartment door (5) without
forgetting the adjusting washer (12).
• Fix the upper hinge (3) onto the opposite
side and then unscrew the hinge pin (4) and
fit it into the other threaded hole, without
forgetting to fit the door separator (13).
• Screw the strip (1) back on (2).
• Remove the plastic plugs (14). Dismantle
the handles (15) and pass them to the other
side. Insert the plastic plugs in the holes that
are left after having changed the position of
the handle.
30
