Configuring with Web Based Management
6.4 "Information" menu
SCALANCE W780/W740 to IEEE 802.11n Web Based Management
118 Configuration Manual, 08/2018, C79000-G8976-C267-13
The following is available in the selection area:
● Logo of Siemens AG
● Display of: "System Location/System Name".
– "System Location" contains the location of the device.
With the settings when the device ships, the IP address of the Ethernet interface is
displayed.
– "System Name" is the device name. With the settings when the device ships, the
device type is displayed.
You can change the content of this display with "System > General > Device.
● Drop-down list for language selection
● System time and date
You can change the content of this display with "System > System Time.
If the system time is not set, the status is
. If the system time is configured, but the
system time cannot be synchronized, a yellow warning triangle
can be seen. Check
whether the time server can be reached. If necessary adapt your configuration. If the
system time is set and/or can be synchronized, the status is
.
In the upper part of the display area, you can see name of the currently logged in user and
the full title of the currently selected menu item.
In the lower part of the display area, you will find:
●
You can log out from any WBM page by clicking the "Logout" link.
●
Shows the name of the device.
●
Shows whether the device is an access point or a client.
●
Each device has one or more LEDs that provide information on the operating state of the
device. Depending on its location, direct access to the device may not always be
possible. Web Based Management therefore displays simulated LEDs. Unused
connectors are displayed as gray LEDs. The meaning of the LED displays is described in
the operating instructions.
If you click this button, you open the window for the LED simulation. You can show this
window during a change of menu and move it as necessary. To close the LED simulation,
click the close button in the LED simulation window.
