Connecting up
4.2 Power supply
SCALANCE XB-200
26 Operating Instructions, 09/2015, C79000-G8976-C359-03
Position and assignment
Figure 4-1 Position of the power supply, for example on the SCALANCE XB213-3
Contact
Assignment
Assignment
Contact
L1+
24 VDC
24 VDC
L2+
M1
Ground
Ground
M2
Functional ground Functional ground
