A.1.9 Modbus command parameters
Addressing the command parameters
You can use Modbus function code 0x06 on the command parameters.
Table A- 13 Command parameters
Offset
Number of
registers
Name
Unit
Format
Value range
Access
60000 1 Reset the device to the factory set-
tings
– Unsigned
short
– W
60001 1 Device reset (without changing the
Modbus address)
– Unsigned
short
– W
60002 1 Reset maximum values – Unsigned
short
0 W
60003 1 Reset minimum values – Unsigned
short
0 W
60004 1 Reset energy counters – Unsigned
short
0 =
all
W
1 = Active energy
import tariff 1
2 = Active energy
import tariff 2
3 = Active energy
export tariff 1
4 = Active energy
export tariff 2
5 = Reactive energy
import tariff 1
6 = Reactive energy
import tariff 2
7 = Reactive energy
export tariff 1
8 = Reactive energy
export tariff 2
9 = Apparent ener-
gy tariff 1
10 = Apparent ener-
gy tariff 2
60005 1 Synchronization of the demand
period
min Unsigned
short
1 … 60 W
60006 1 Tariff switchover – Unsigned
short
0 = On-peak
1 = Off-peak
W
60007 1 Acknowledge the diagnostics bits
1)
(cf. stored bits in unsigned long
beginning offset 205)
– Unsigned
short
0 … ffffh W
60008 1 Switch outputs (if parameterized) – Unsigned
short
0ffh … 1ffh
W
Byte0 0 =
Output 0.0
