Article number 6FB1141-1AT11-3W
E2
6FB1141-2AT10-3W
E2
6FB1141-3AT10-3W
E2
Active power input (standby
mode)
5 W
Digital inputs
Control inputs isolated Yes
Control inputs p-switching Yes
Input voltage
• permissible voltage at in‐
put, min.
10 V; Observe polarity !
• permissible voltage at in‐
put, max.
28 V; Observe polarity !
Input current
• for signal "1", min.
9 mA
• for signal "1", max.
27 mA
Digital outputs
Relay outputs
Switching capacity of contacts
– at 30 V DC, min.
0.01 A
– at 30 V DC, max.
1 A 0.5 A
Mechanical data
Opening width of door, min. 0.3 m
Opening width of door, max. 5 m
Weight of door, max. 600 kg
Operating cycle frequency of
door, max.
180 1/h
Counterforce, max. 75 N
Kinetic energy, max. 100 J
Interfaces
Interfaces/bus type without PROFIBUS according
to IEC 61784-3
PROFINET IO accord‐
ing to Conformance
Class C
Number of bus nodes 32
Isolation
Overvoltage category 2
Degree of pollution 2
Degree and class of protection
IP degree of protection IP20
Standards, approvals, certi‐
cates
Certicate of suitability accord‐
ing to EN 81
No
CE mark Yes
UL approval Yes
EAC (formerly Gost-R) Yes
TÜV Inspectorate approval Yes
Controllers
5.8 Technical specications
ATD4xxW for industrial applications
System Manual, 06/2022, A5E51901827B AA 173
