Commissioning and Diagnostics
6-66
ET 200S Distributed I/O System
EWA-4NEB 780602402-12
”Process interrupts lost” diagnosis
For the modules
• 2DI 24 VDC High Feature (6ES7 131-4BB00-0AB0)
• 4DI 24 VDC High Feature (6ES7 131-4BD00-0AB0) and
• 4DI 24--48 VUC High Feature (6ES7 131-4CD00-0AB0)
the ”Process interrupt lost” diagnosis is not currently available. This function will be
implemented in a future product level of the IM151-3 PN.
Note
Process interrupts should not be used for process-related purposes (such as
periodic generation of process interrupts), because they may be lost in the overall
system.
6.2.6 Diagnostics with STEP 7
In chapter Description Page
6.2.6.1 Reading Diagnostics Data 6-67
6.2.6.2 Channel diagnostics 6-68
6.2.6.3 Diagnostics in the case of invalid ET 200S configuration states on
the PROFINET IO
6-70
6.2.6.4 Diagnostics in the case of interruption of the ET 200S backplane
bus
6-70
6.2.6.5 Diagnostics in the case of failure of the load voltage from the power
module
6-71
