Siemens SIMATIC ET 200S - 2 AI TC Standard analog electronic module (6 ES7 134-4 JB00-0 AB0)

Analog Electronic Modules
12-90
ET 200S Distributed I/O System
EWA-4NEB 780602402-12
12.16 2AI TC Standard analog electronic module
(6ES7 134-4JB00-0AB0)
Order number
6ES7 134-4JB00-0AB0
Properties
• 2 inputs for thermocouples or voltage measurement
• Input ranges:
-- Voltage measurement:
¦ 80 mA, resolution 15 bits + sign
-- Thermocouples: Type E, N, J, K, L, S, R, B, T, resolution 15 bits + sign
• Isolated for load voltage L+
• Linearization of the sensor characteristic curves
• Allowable common-mode voltage 2 VAC
SS
Terminal assignment
The following table shows the terminal assignment of the 2AI TC Standard for the
various terminal modules:
Voltage measuring as with 2AI U Standard (see Chap. 12.5).
Table 12-47 Terminal assignment of the 2AI TC Standard
View
Terminal assignment Remarks
M
1--
M
0--
AUX1 (e.g. PE)
2
3
4
6
7
8
1
5
M
1+
M
0+
AUX1 (e.g. PE)
M
ana
M
ana
TM-E15S24-A1 and 2DA TC Standard
CH0 CH1
AUX1 must be
assigned to PE.
AA
Channel 0: Terminals 1 to A4
Channel 1: Terminals 5 to A8
M+: Measuring cable positive
M--: Measuring cable
negative
M
ana
: Module ground
