Siemens SIMATIC HMI series - Functions for Service and Commissioning

Parameterizing the Mobile Panel
5.15 Functions for service and commissioning
Mobile Panels 2nd Generation
144 Operating Instructions, 09/2018, A5E33876626-AC
4. Confirm your entries with "Save".
Note
For the "E
-stop button evaluated by safety relay" and "E-stop button evaluated by
PROFIsafe" operating modes:
•
If password protection is already enabled, the password prompt is displayed.
•
If no password has been assigned, you are prompted to assign a password.
Enter the password and confirm
your entry.
You can find additional information on password protection in the section
"
Entering and deleting a password (Page 105)".
The dialog closes. Information text ④ shows: "Operation mode successfully stored in
Connection Box"
5. Close the "Safety operation" dialog with "Close".
The operating mode is assigned.
See also
Using the HMI device in password-protected security mode (Page 89)
5.15
Functions for service and commissioning
5.15.1
Saving to external storage medium – backup
You can use this function to back up the operating system, applications and data from the
flash memory of the HMI device to an external storage medium.
Use the following storage media:
● For KTP700, KTP700F, KTP900, KTP900F Mobile: A SIMATIC HMI Memory Card or an
industrial USB memory stick
● KTP400F Mobile: An industrial USB memory stick
