Safety Integrated Functions in
SINAMICS Drive Systems
6.7 Control via PROFIsafe
Connection of the SINAMICS S120 to the Technology CPU
Product Information, 09/2011, A5E00480378-04
203
Summary
Table 6- 4 Characteristics with and without support of the extended functions
With support Without support
StatuswordSafety and SafeSpeedLimit
variables in the TO DB of the axis
Contents of the variable are valid Contents of the variables not relevant
Errors 8140, 8142 and 8143 Signaled Not signaled
Error 8010 with SS1 and SS2 With SS1, suppressed until axis is at
standstill.
With SS2, fully suppressed.
Occurs immediately upon selection of
SS1 or SS2
Release_Disable during SS1 or SS2 Has effect on drive, even during OFF3
ramp
Has no effect on drive.
Follow-up mode with SS1 and SS2 Automatic follow-up mode. No automatic follow-up mode. User
program cannot assume follow-up
mode.
6.7 Control via PROFIsafe
Introduction
The safety functions of the drive can be controlled via terminals and the TM54F module as
well as the PROFIsafe message frame 30. Each drive with a configured PROFIsafe in the
drive unit represents a PROFIsafe slave (F-slave) with fail-safe communication to the F-host
via PROFIBUS.
A separate PROFIsafe message frame is created for each drive (PROFIsafe slot).
Control of the basic functions via the Control Unit and Motor Module (p9601.0/p9801.0)
terminals may be enabled in parallel. In this way, the STO, SBC, and SS1 functions
(time controlled) can be selected via PROFIsafe as well as via the on-board terminals on the
Control Unit and Motor Module.
