Siemens SIMATIC S7-300 Module data Function Manual

03/2013 5 Statistics/export
5.1 Multi-machine views
© Siemens AG 2006-2012 All Rights Reserved
SINUMERIK Integrate AMB, AMC, AMM, Function Manual (FH) - 03/2013
5-257
Fig. 5-23: Comparing configurations
Fig. 5-24: Comparing configurations
Function Description Type
Reference
machine
Display of the reference machine which is the
machine selected for comparison.
All configurations are represented by type with
their names.
Configurations are marked in color with the
following meaning:
Orange: Different configurations
Light blue: Identical configurations
DISPLAY
Number of
comparison
machines: x
Shows the number of machines in the selected
group that are compared.
All configurations are shown according to type
with the individual names of each machine in the
group.
Configurations are marked in color with the
following meaning:
Orange: Different configurations
Light blue: Identical configurations
DISPLAY
