List of Parameters
Parameters
1-245
© Siemens AG 2007 All Rights Reserved
SINAMICS G120 Control Units CU240S, Edition 05/2007
Description: Sets the ramp-down time for the internal PID-MOP ramp-function generator.
The setpoint is changed from limit defined in P1082 down to zero within this time.
Notice: Refer to: P2247, P1082
Description: Displays output setpoint of motor potentiometer in [%].
Description: Enables function of PID controller.
Values: 0: PID as setpoint
1: PID as trim
Dependency: Active when PID loop is enabled (see P2200).
Description: Defines setpoint source for PID setpoint input.
This parameter allows the user to select the source of the PID setpoint. Normally, a digital setpoint is selected either
using a fixed PID setpoint or an active setpoint.
Description: Selects trim source for PID setpoint.
This signal is multiplied by the trim gain and added to the PID setpoint.
p2248[0...2] PID-MOP ramp-down time of the RFG / PMOP rampdown time
Access level: 2 P-Group: Technology Data type: Floating Point
Quick comm. NO Active: NO Data set: DDS
Can be changed: U, T
Min Max Factory setting
0.00 [s] 1000.00 [s] 10.00 [s]
r2250 CO: Output setpoint of PID-MOP / PMOP outp. setp
Access level: 2 P-Group: Technology Data type: Floating Point
Unit: [%] Data set: -
p2251 PID mode / PID mode
Access level: 3 P-Group: Technology Data type: Unsigned16
Quick comm. NO Active: YES Data set: -
Can be changed: T
Min Max Factory setting
0 1 0
p2253[0...2] CI: PID setpoint / PID setpoint
Access level: 2 P-Group: Technology Data type: Unsigned32
Quick comm. NO Active: NO Data set: CDS
Can be changed: U, T
Min Max Factory setting
- - 0
p2254[0...2] CI: PID trim source / CI:PID trim source
Access level: 3 P-Group: Technology Data type: Unsigned32
Quick comm. NO Active: NO Data set: CDS
Can be changed: U, T
Min Max Factory setting
- - 0
