Configuring the fieldbus
7.6 Communication via RS485
Inverter with CU230P-2 Control Units
Operating Instructions, 11/2013, FW V4.6.6, A5E02430659B AG
177
Binary Input Objects
Instance
ID
Object name
Description
Possible
values
Text active /
text inactive
Access
type
Parameter
BI0
DI0 ACT
State of DI 0
ON/OFF
ON/OFF
R
r0722.0
BI1
DI1 ACT
State of DI 1
ON/OFF
ON/OFF
R
r0722.1
BI2
DI2 ACT
State of DI 2
ON/OFF
ON/OFF
R
r0722.2
BI3
DI3 ACT
State of DI 3
ON/OFF
ON/OFF
R
r0722.3
BI4
DI4 ACT
State of DI 4
ON/OFF
ON/OFF
R
r0722.4
BI5
DI5 ACT
State of DI 5
ON/OFF
ON/OFF
R
r0722.5
BI7
DI7 ACT
State of AI 1 - used as DI
ON/OFF
ON/OFF
R
r0722.11
BI8
DI8 ACT
State of AI 2 - used as DI
ON/OFF
ON/OFF
R
r0722.12
BI10
DO0 ACT
State of DO 0 (relay 1)
ON/OFF
ON/OFF
R
read r747.0
BI11
DO1 ACT
State of DO 1 (relay 2)
ON/OFF
ON/OFF
R
read r747.1
BI12
DO2 ACT
State of DO 2 (relay 3)
ON/OFF
ON/OFF
R
read r747.2
Binary Output Objects
Instance
ID
Object name
Description
Possible
values
Text active /
text inactive
Access
type
Parameter
BO0
DO0 CMD
Controls DO 0 (relay 1)
ON/OFF
ON/OFF
C
p0730
BO1
DO1 CMD
Controls DO 1 (relay 2)
ON/OFF
ON/OFF
C
p0731
BO2
DO2 CMD
Controls DO 2 (relay 3)
ON/OFF
ON/OFF
C
p0732
Binary value Objects
Instance
ID
Object name
Description
Possible values
Text
active
Text
inactive
Access
type
Parameter
BV0
RUN / STOP
ACT
Inverter status regardless of
command source
RUN / STOP
STOP
RUN
R
r0052.2
BV1
FWD / REV
Direction of rotation regardless of
command source
REV / FWD
FWD
REV
R
r0052.14
BV2
FAULT ACT
Inverter fault
FAULT / OK
FAULT
OK
R
r0052.3
BV3
WARN ACT
Inverter warning
WARN / OK
WARN
OK
R
r0052.7
BV4
MANUAL /
AUTO ACT
Indicates the source of the
manual/auto inverter control
AUTO / MANUAL
AUTO
LOCAL
R
r0052.9
BV7
CTL
OVERRIDE
ACT
ACT displays the inverter's control
unit from the BACnet override
control unit via BV93.
Note that the operator panel's
"Manual" operating mode has a
higher priority than the BACnet
override control.
ON/OFF
0
1
R
r2032[10]
BV8
AT SET-
POINT
Setpoint reached
YES / NO
YES
NO
R
r0052.8
