Siemens SINAMICS G120 - Page 383

Technical data
12.2 Technical data, Power Modules
Inverter with CU230P-2 Control Units
Operating Instructions, 11/2013, FW V4.6.6, A5E02430659B AG
383
Table 12- 11 PM230, IP20, Frame Sizes F, 3 AC 380 V … 480 V
Order No. - without filter
Order No. - with filter
6SL3210…
6SL3210…
…1NE31-1UL0
…1NE31-1AL0
…1NE31-5UL0
…1NE31-5AL0
LO power
LO input current
LO output current
55 kW
102 A
110 A
75 kW
135 A
145 A
HO power
HO input current
HO output current
45 kW
84 A
90 A
55 kW
102 A
110 A
Fuse according to IEC
Fuse according to UL
3NE1224-0
3NE1224-0
3NE1225-0
3NE1225-0
Power loss
1.4 kW
1.9 kW
Required cooling air flow
150 l/s
150 l/s
Cross section of line and motor cables 35 … 120 mm
2
2 … 4/0 AWG
35 … 120 mm
2
2 … 4/0 AWG
Tightening torque for line and motor cables
13 Nm / 115 lbf in
13 Nm / 115 lbf in
Weight, unfiltered
Weight, filtered
33 kg
48 kg
33 kg
48 kg
