Operation
6.8 Communication via PROFINET IO
Inverter chassis units
268 Operating Instructions, 07/2016, A5E00331449A
6.8.4.9
PROFIenergy applications
Applications for PROFIenergy and for programming with SIMATIC S7 can be found under
the following link: PROFIenergy applications
(http://support.automation.siemens.com/WW/view/en/20229805/136000&cspltfrm=12&cssw=
0&csbinh=0).
6.8.4.10
Function diagrams and parameters
Function diagram
FP 2381
PROFIenergy - Control commands / query commands
FP 2382
PROFIenergy - States
FP 2610
Sequence control - Sequencer
Parameter
•
r5600
Pe hibernation ID
•
p5602[0...1]
Pe hibernation pause time, minimum
•
p5606[0...1]
Pe hibernation duration, maximum
•
p5611
Pe energy
-saving properties, general
•
p5612[0...1]
Pe energy
-saving properties, mode-dependent
•
r5613.0...1
CO/BO: Pe energy
-saving active/inactive
•
p5614
BI: Set Pe switching on inhibited signal source
6.8.5
Support of I&M data sets 1...4
Identification & Maintenance (I&M)
I&M data records contain information for a standardized and simplified identification and
maintenance of PROFINET devices. I&M data sets 1...4 contain plant-specific information,
such as the installation location and date. PROFINET supports I&M data sets 0...4.
I&M data sets 1...3 can be set with the SIMATIC Manager (STEP 7) and also with HW
Config (STEP 7).
