Description
3.2 Order numbers / Type designations
Installation and Operating Instructions SINAMICS G180
Operating Instructions, 02/2019, 4BS0751-007
35
Example
Designation
Option
Meaning
A - Number of pulses in the input
A
6-pulse input
F 12-pulse input
K
18-pulse input
L 24-pulse input
0 Mechanical design
0
Compact device with air cooling
2
Compact device Plus with air cooling
3
Compact device with water cooling
7
Cabinet unit with water cooling
8
Cabinet unit with air cooling
9
Special version
7 Modification status
5
Modification status 5
6
Modification status 6
7
Modification status 7
4 Line voltage
4
400 V unit
5
500 V unit
6
690 V unit
9
950 V unit
0
Number of parallel line-converter
systems
0
Single device without system management
1
Single device with system management
2 ... 7
Multiple device with corresponding number of parallel systems
and system management units
0-
Number of parallel machine-
converter systems
0
Single device without system management
1
Single device with system management
2 … 7
Multiple device with corresponding number of parallel systems
and system management units
055 Achievable shaft output [kW] for
continuous output current
… If the first position is 9, the other two digits show the power in
kW * 100.
Other version designation
e.g. A type code O B D I M 4
The other version designation of the converter consists of the type code and seven other
characters. This designation is specified on the rating plate. It is used in commercial written
communication and is as follows:
Example
Designation
Option
Meaning
A Accessories
A
Standard accessories
D
Accessories with bypass for mains operation with direct activation
N Accessories according to NAMUR Guideline NE37 with Test-Normal
switch
Q
Accessories with main switch, external handle
W
Accessories with main switch, internal handle
S Accessories with main switch, main contactor, EMERGENCY STOP in
door and local/remote switch
Z
Customer-specific accessories
