Siemens SINAMICS V20 Inverter - Mechanical Specifications

Technical specifications
SINAMICS V20 Inverter
Getting Started, 07/2012, A5E03728127
63
Three phase 400 V inverters
Frame
size
Power
rating
[kW]
Current rating [A] at PWM frequency
PWM frequency range: 2 ... 16 kHz (default: 4 kHz)
10 kHz 12 kHz 14 kHz 16 kHz
40 °C 50 °C 60 °C 40 °C 50 °C 60 °C 40 °C 50 °C 60 °C 40 °C 50 °C 60 °C
A 0.37 0.8 0.5 0.4 0.7 0.5 0.3 0.6 0.4 0.3 0.5 0.4 0.3
A 0.55 1.0 0.7 0.5 0.9 0.6 0.4 0.8 0.5 0.4 0.7 0.5 0.3
A 0.75 1.3 0.9 0.7 1.1 0.8 0.6 1.0 0.7 0.5 0.9 0.6 0.4
A 1.1 1.9 1.3 0.9 1.6 1.1 0.8 1.4 1.0 0.7 1.2 0.9 0.6
A 1.5 2.5 1.7 1.2 2.1 1.4 1.0 1.8 1.3 0.9 1.6 1.1 0.8
A 2.2 3.4 2.4 1.7 2.8 2.0 1.4 2.5 1.7 1.2 2.2 1.6 1.1
B 3.0 4.4 3.1 2.2 3.7 2.6 1.8 3.3 2.3 1.6 2.9 2.0 1.5
B 4.0 5.3 3.7 2.6 4.4 3.1 2.2 4.0 2.7 1.9 3.5 2.5 1.8
C 5.5 7.5 5.3 3.8 6.3 4.4 3.1 5.6 3.9 2.8 5.0 3.5 2.5
D 7.5 9.9 6.9 5.0 8.3 5.8 4.1 7.4 5.1 3.6 6.6 4.6 3.3
D 11 15.0 10.5 7.5 12.5 8.8 6.3 11.3 7.8 5.5 10.0 7.0 5.0
D 15 18.6 13.0 9.3 15.5 10.9 7.8 14.0 9.6 6.8 12.4 8.7 6.2
Motor control
Control methods Linear V/F, quadratic V/F, multi-point V/F, V/F with FCC
Output frequency range Default range: 0 ... 599 Hz
Resolution: 0.01 Hz
Maximum overload cycle 150 % rated for 60 seconds followed by 94.5 % rated for 540 seconds (average 100 %
rated)
Mechanical specifications
3 AC 400 V
Frame size A Frame size D
With fan Without fan
Frame size B Frame size C
7.5 kW 11 kW 15 kW
W 90 90 140 184 240
H 166 150 160 182 206.5
Outline dimensions
(mm)
D 145.5 145.5 164.5 169 172.5
unfiltered 1.0 0.9 1.6 2.4 3.7 3.7 3.9 Net weight (kg)
filtered 1.1 1.0 1.8 2.6 4.0 4.1 4.3
Gross weight (kg) 1.4 2.1 3.0 5.0
Mounting methods
• Cabinet panel mounting (frame sizes A ... D)
• Push-through mounting (frame sizes B ... D)
