Operation Type
1)
Meaning W
2)
TP
3)
SA
4)
Description see
5)
1)2)3)4)5)
for explanations, see legend (Page 1197).
FROM K The action is executed if the condition is fulfil‐
led once and as long as the synchronous ac‐
tion is active
- + FM-SA
FTOC P Change fine tool offset - + FM-SA
FTOCOF
6)
G Online fine tool offset OFF m + PM-NC
FTOCON G Online fine tool offset ON m + PM-NC
FXS K Travel to fixed stop ON m + + PM-NC
FXST K Torque limit for travel to fixed stop m + + PM-NC
FXSW K Monitoring window for travel to fixed stop + + PM-NC
FZ K Tooth feedrate m + PM-NC
Operations G ... L
Operation Type
1)
Meaning W
2)
TP
3)
SA
4)
Description see
5)
1) 2) 3) 4) 5)
for explanations, see legend (Page 1197).
G0 G Linear interpolation with rapid traverse (rapid
traverse motion)
m + PM-NC
G1
6)
G Linear interpolation with feedrate (linear inter‐
polation)
m + PM-NC
G2 G Circular interpolation clockwise m + PM-NC
G3 G Circular interpolation counter-clockwise m + PM-NC
G4 G Dwell time, preset s + PM-NC
G5 G Oblique plunge-cut grinding s + PM-NC
G7 G Compensatory motion during oblique plunge-
cut grinding
s + PM-NC
G9 G Exact stop - deceleration s + PM-NC
G17
6)
G Selection of working plane X/Y m + PM-NC
G18 G Selection of working plane Z/X m + PM-NC
G19 G Selection of working plane Y/Z m + PM-NC
G25 G Lower working area limitation s + PM-NC
G26 G Upper working area limitation s + PM-NC
G33 G Thread cutting with constant lead m + PM-NC
G34 G Thread cutting with linear increasing lead m + PM-NC
G35 G Thread cutting with linear decreasing lead m + PM-NC
G40
6)
G Tool radius compensation OFF m + PM-NC
G41 G Tool radius compensation left of contour m + PM-NC
G42 G Tool radius compensation right of contour m + PM-NC
G53 G Suppression of current zero offset (non-mo‐
dal)
s + PM-NC
G54 G 1st settable zero offset m + PM-NC
G55 G 2nd settable zero offset m + PM-NC
Tables
4.1 Operations
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 1213
