● For REAL data types, only the number of places after the decimal point can be changed.
Changing the type is illegal and generates an error message in the easyscreen_log.txt. file.
Example:
Var1.typ = "IBW"
Var2.typ = "R3"
Numerical formats
Numbers can be represented in either binary, decimal, hexadecimal or exponential notation:
Binary B01110110
Decimal 123.45
Hexadecimal HF1A9
exponential -1.23EX-3
Examples:
VAR1 = HF1A9
REG[0]= B01110110
DEF VAR7 = (R//-1.23EX-3)
Note
When codes are generated with the "GC" function, only numerical values in decimal or
exponential notation are evaluated, but not those in binary or hexadecimal notation.
See also
Variable parameters (Page 92)
Variables
5.11 Details on the variable type
SINUMERIK Integrate Run MyScreens (BE2)
100 Programming Manual, 12/2017, 6FC5397-1DP40-6BA1
